Objective 3.2 â Configure and Manage Logical Virtual Private Networks (VPNs):

Configure IPSec VPN service to enable site to site communication
Configure L2 VPN service to stretch multiple logical networks across geographical sites
Configure SSL VPN service to allow remote users to access private networks

NEW QUESTION 11
Enable load balancing for the development environment allowing HTTPS access to the Dev-Web-01a and Dev-Web-02a servers.
Requirements:
vCenter: vcsa-01a.corp.local
Credentials: [email protected]
Self-signed certificate parameters:
Common Name: 192.168.5.100
Organization Name: ABC Medical
Organization Unit: IT
Locality: Palo Alto
State: CA
Country: United States
Message Algorithm: RSA
Key Size: 2048
Number of Days: 365
Web Servers: Dev-Web-01a, Dev-Web-02a
Use the secondary IP address of 192.168.5.100
New connections should consider current connections among all available members of the pool.
The web servers will not have SSL certificates installed. The web team has indicated that analytics based on source IP should be available.
Ensure all requirements have been met.
HOL LAB for Practice:
Load Balancer and other questions 7, 8, 9
See the explanation part for complete solution.

Answer:

Explanation:
SOLUTION:
Create Secondary address on Uplink Interface.
Generate CSR using the give details.
Enable Load-Balancer, create Profile, create Virtual Server.
Dev-Edge -> Manage -> Settings -> Interfaces -> Edit and add secondary IP address: 192.168.5.100

Create CSR as per given details from the question:
Dev-Edge -> Manage -> Settings -> Certificate -> Actions -> Generate CSR

Dev-Edge -> Manage -> Settings -> Certificate -> Actions -> Self Sign Certificate: Days = 365

Dev-Edge -> Manage -> Load Balancer -> Global Configuration -> Edit

Enable Load Balancer

Create Application Profile:

Check box for inser-forward-for-httpheader also below

Create new Pool:

Add both Web member servers:

Add Virtual Servers:

NEW QUESTION 12
The security team has submitted two requests to change or limit access in NSX for Site A's vCenter groups.
Requirements:
NSX Manager: nsxmgr-01a.corp.local
vCenter: vcsa-01a.corp.local
Credentials: [email protected] / VMware1!
Grant all members of vCenter group AuditTeam the minimal access necessary to view NSX Data Security policy configurations for all objects in Site A.
Grant all members of vCenter group ScanTeam the minimal access necessary to enable them to start and stop data security scans in Site A.
Ensure that the principles of least privilege are adhered to.
NOTE:
The Active Directory groups associated with the vCenter groups has already been preconfigured.
HOL LAB for Practice:
See the explanation part for complete solution.

Answer:

Explanation:
SOLUTION:
select Home. select administrator. select domain vsphere.local. select groups.
click + sign. enter group name AuditTeam click ok. do same for ScanTeam.

[email protected]

[email protected]

select datacenter A.
select manage select permission click on + Sign.
select Assign role read only. select all privileges click on Add
select AuditTeam and select ScanTeam. check propagate to childern. and click ok

NEW QUESTION 13
Configure the Layer 3 connectivity between the newly created Dev-segments by assigning them to a new DLR named Dev-DLR-NEW.
Requirements:
vCenter: vcsa-01a.corp.local
Ccredentials: [email protected] . VMware1!
Default GW for Dev-subnets:
Dev-Web-Tier-01-NEW172.16.10.1/24
Dev-App-Tier-01-NEW172.16.20.1/24
Dev-DB-Tier-01-NEW172.16.30.1/24
DLR Settings:
DLR Name: Dev-DLR-NEW
Uplink IP Address: 192.168.6.5/30
Interface: Dev-Transit
Password: VMware1!WMware1!
Cluster: Management & Edge Cluster
Ensure east-west routing has been optimized.
The control plane failover should begin 15 seconds on logical switch HA-VXLAN.
Ensure secure shell is available.
Connect the Web, App and DB virtual machines to their respective dev tiers.
Dev-web-01, Dev-web-02a, Dev-web-04a
Dev-app-01a
Dev-db-01a
HOL LAB for Practice:
also deploy Distributed logical router DLR in the same way the lab.
See the explanation part for complete solution.

Answer:

Explanation:
SOLUTION:
Add VMs to respective Logical Switches:

No need for below
To change the control plane failover within 15 seconds use the RESTClient as shown below or the Postman application in Chrome.
Open Firefox
Open RESTClient from Firefox
Authentication
Basic Authenticaion

Admin
VMware1!

Headers
Custom Headers

Content-Type
Application/xml

Note down the edge id of newly created DLR (in exam its edge-12)

There will be a NSX API guide on desktop and look for "declaredeadtime".
Or memorize below string:
URL: https://192.168.110.15/api/4.0/edges/edge-10/highavailability/config Note: in exam its edge-12 but make sure!

Change the value to 15
Body:
<highAvailability>
<declareDeadTime>15</declareDeadTime>
</highAvailability>

NEW QUESTION 14
Complete the configuration of Dev-Edge to allow north-south routing connectivity for the new Dev-segment.
Workloads will have overlapping IP addressing with production workloads. The developers will RDP into a jump host server (Dev-Jumphost) on the Dev-Web segment. An RDP shortcut named To Dev-JumpHost.rdp has been created on the ControlCenter Desktop.
The following has been preconfigured on Dev-Edge:
The uplink interface on the Dev-Edge has been pre-configured to communicate the upstream Gateways and attached to Dev-to-PGs-Transit.
Dev-DLR-NEW and Dev-Edge interfaces have been preconfigured to communicate with each other.
ECMP has been disabled.
Requirements:
vCenter: vcsa-01a.corp.local
Credentials: [email protected] / VMware1!
Dev-Jumphost information:
Credentials: administrator / VMware1!
Internal IP of Dev-Jumphost: 172.16.10.100
External IP of Dev-Jumphost: 192.168.5.100
Connection Information:
Dev-Edge-Uplink IP: 192.168.5.3/24
Dev-Edge-Internal IP : 192.168.6.6/30
Preimeter-Gateway-01-Internal IP: 192.168.5.1/24
Preimeter-Gateway-02-Internal IP: 192.168.5.2/24
Logical switch: Dev-to-PGs-Transit
ECMP: Enabled.
BGP AS: 65001
Credentials for all Edge Devices: admin / VMware1!VMware1!
The networking team requires BGP as a routing protocol with an AS of 65001 for North-bound access for the Dev-environment.
Use the fewest number of static routes and utilize network prefixes to ensure accessibility to the Dev-Web-Tier-01-NEW within the Dev-environment.
Ensure Dev-Jumphost is on Dev-Web-Tier-01-NEW.
Ensure the ability to RDP into the Dev-Jumphost server from the production network (ControlCenter).
HOL LAB for Practice:
module, it will be use full for other question like 20 and 22
See the explanation part for complete solution.

Answer:

Explanation:
SOLUTION:

Static Routes on Dev-Edge:
Network:172.16.0.0/16
Next Hop:192.168.6.5
Interface:Dev-Transit

Uplink
192.168.5.100
Tcp
3389
172.16.10.100
3389

(1) Go to Vcenter-a. select network & Security. select NsX Edge.
(2) check the PGW01 configuration if everything is ok no need to do any changes specially ip address and routing. if not than select PGW01. select Manage. select routing select global configuration and enable routing. click publish changes.
be sure ECMP is enabled.
select BGP Configuration. click edit. select enable BGP, select Enable Graceful restart (select enable Default originate). enter AS 65001 click ok click publish changes

SSH to both Perimeter Routers and verify BGP neighborship.
Username: admin
Password: VMware1!VMware1!

Add jumphost VM to Dev-Web-Tier-01-NEW Logical Switch

NOTE:
192.168.5.100 interface is created in the next task only. So after testing the next task output, you should be able to get the RDP login.

NEW QUESTION 15
Build a multi-tier network capable of supporting application virtual machines deployed across multiple vCenter instances.
Requirements:
vCenter: vcsa-01a.corp.local
Credentials: [email protected] / VMware1!
Resource Pools: Management and Edge Cluster 1A
The underlying physical network does not support multicast.
All new items created must have a prefix of "U" followed by their function name and a suffix of "New".
i.e. U-App-Tier-NEW.
Create a LS for HA management interface calle U-HA-VXLAN=NEW but do not enable HA on any of the edge devices deployed.
Deploy logical switches using separate subnets for the three tier application shared by both NSX Manager instances.
Deploy the required east-west routing component used across multiple vCenter instances for the multi-tier network.
Utilize a default gateway up to the Perimeter-Gateway02 (tenant router) from the east/west router.
Utilize a static route from the tenant router to reach the three tiers of the application.
Subnets for the tiers:
172.7.10.0/24 for the Web Tier.
172.17.20.1/24 for the App Tier.
172.17.30.0/24 for the Database Teir.
Use the first available IP address for the router on each of the tiers.
Subnet for the Transit VXLAN uplink from the application tier routing to the tenant router.
192.168.190.0/29
Uplink IP address of the application tier should be the first available IP address.
Downlink from the tenant router will use the second available IP addresses.
The password for new edge device(s) must be VMware1!VMware1!
Add all virtual machines with a prefix "universal-" to their respective segments.
Ensure all LIFs are reachable from ControlCenter.
HOL LAB for Practice:
See the explanation part for complete solution.

Answer:

Explanation:
SOLUTION:
universal transport zone
logical switches
U-HA-VXLAN-NEW
U-Transit-NEW
U-Web-Tier-NEW
U-App-Tier-New
U-DB-Tier-New
New DLR U-DLR-NEW
HA Interface - U-HA-VXLAN-NEW
Interface below
- U-Transit-NEW uplink 192.168.190.1
- U-Web-Tier-NEW internal 172.17.10.1
- U-App-Tier-NEW internal 172.17.20.1
- U-Db-Tier-NEW internal 172.17.30.1
Gateway
-U-Transit-NEW
Ip 192.168.190.2
PGW02 vnic4 U-Transit-NEW 192.168.190.2

Create 5 logical switches
U-Transit-NEW

U-Web-Tier-NEW

U-App-Tier-NEW

U-DB-Tier-NEW

Add VMs to relevant newly created Logical Switches.

No need

Create new Universal Logical (Distributed) Router:

U-DLR-NEW

U-Uplink-NEW(U-Transit-NEW)

Select U-Transit-NEW logical swicth here

Perimeter-Gateway-02

To-Universal-DLR

Select U-Transit-NEW

172.17.0.0/16
192.168.190.1
To-Universal-DLR

NEW QUESTION 16
Management requires you to build a new logical topology for a new application that will include a hardware search appliance (HAS). The new application must contain a web tier and database tier on separate IP domains. Use the existing App01-DLR to complete the task.
Requirements:
vCenter: vcsa-01.corp.local
Credentials: [email protected] / VMware1!
vDS: vds-mgt-edge-a
Existing DLR Name: App01-DLR
New object prefix - App01
New object suffic - New
Create a new distributed port group for this task named vds-HSA-NEW.
The HAS must reside on the same IP subnet as the database.
The new application must contain a web tier and database tier on separate domains to be used at a future date.
Once deployed the HAS will be connected to a network with VLAN ID 500.
The proper physical switch ports for the uplinks have already been trunked to include VLAN 500.
VLANs configured in the compute racks are isolated to a single rack.
Any objects/items created must be named with a prefix of App01 and a suffix containing their function with NEW (for example: App01-Function-NEW) NOTE:
The hardware appliance and application virtual machines have not been deployed. Attempts to connectivity to the appliance will not succeed.
HOL LAB for Practice:
Bridging and other questions 7, 8, 9 and LAB - HOL-1925-02 Module 1
See the explanation part for complete solution.

Answer:

Explanation:
SOLUTION:
Step 1: From SiteA vCenter web client -> Networking -> Data Center SiteA -> create a new distribution port group named vds-HAS-NEW with VLAN ID 500 in vds-mgmt-edge.

Create LS on 192.168.110.15 = App01-WebTier-NEW

Create LS on 192.168.110.15 = App01-DBTier-NEW

NSX Edges -> App01-DLR

8) got NsX Edge and select App01-DLR. select Manage, select settings and click on + Sign (9) Enter interface name App01-Web-New, select type internal. select App01-Webtier-New LS Enter ip address 192.168.1.1/24. repeat the same steps for App01-DBtier-New but take ip addres
192.168.2.1 /24

Name: App01-Bridge-NEW
Logical Switch: App01-DBTier-NEW
Distributed Port Group: vds-HAS-NEW

(11) be sure under App01-DB-New the bridging is enable.

NEW QUESTION 17
Create a security policy for specific web-based applications.
Requirements:
vCenter: vcsa-01a.corp.local
NSX Manager: 192.168.110.15
Credentials: [email protected] . VMware1!
New Security Policy Name: Web-Policy-NEW
New Web Security Group Name: Secure-Web-NEW
New NSX Tag: web-security-NEW
New App Security Group Names: Secure-App-NEW
Create a new security policy to deny HTTP/HTTPS from App server to the Web Server.
Create a new Security Group for the Web servers to meet the following requirements:
Existing and future virtual machines that have in their name dev-web should be added.
Any VM with a NSX tag of web-security-NEW should be added to this policy.
Ensure virtual machine dev-web-04a has been then tagged.
Create a new security group for the App server that has virtual machine dev-app-01a added.
HOL LAB for Practice:
See the explanation part for complete solution.

Answer:

Explanation:
SOLUTION:
Requirements:

Create new Security Group = Secure-Web-NEW

In security tag put equal

Create new Security Policy as per given details:

Right Click -> Apply Policy ->

NEW QUESTION 18
Provide automatic IP assignment for the servers on the DEV-DB-Tier-01-NEW segment.
Requirements:
vCenter: vcsa-01a.corp.local
Credentials: [email protected] / VMware1!
Edge: Dev-Edge
Automatically allocate IP addreesses in the 172.16.30.100-149 range.
Lease time: 1 hour
Ensure hosts that receive an IP assignment will be able to reach the other Dev subnets.
The legacyhost-NEW with the MAC address 40:00:00:00:00:01 must always be assigned 172.16.30.99 Ensure other parameters match those of the dynamic allocation mechanism (Task1).
Enable logging with the highest level of detail for automatic IP allocations.
Ensure all requirements have been met.
NOTE:
Do not configure DHCP Relay agent on the Dev-DLR-NEW as this will be done by another administrator.
HOL LAB for Practice:
DHCP and other questions 7, 8, 9
See the explanation part for complete solution.

Answer:

Explanation:
SOLUTION:

Add Pool as per given details:

Add Pool as per given details:

NEW QUESTION 19
Provide cross vCenter security functionality for the Universal Web Multi-Tiered network application.
Requirements:
vCenter: vcsa-01a.corp.local
Credentials: [email protected] / VMware1!
New Section Name: Universal-Rules-New
Networks:
Web-Tier: 172.17.10.0/24
App-Tier: 172.17.20.0/24
DB-Tier: 172.17.30.0/24
Secure east/west network communication for each of the three tiers allowing only.
Firewall Rule section Name: Universal-Rules-NEW
Web Tier: any source address incoming on TCP port 80 and 443
Application Tier: access from the web tier on the incoming TCP port 8443 Database Tier: access from the application tier on the incoming TCP port 3306 Traffic that does not meet the above requirements should be blocked.
NOTE:
This rule must only affect the universal tiers.
HOL LAB for Practice:
See the explanation part for complete solution.

Answer:

Explanation:
SOLUTION:
Add new Section under Firewall.

Universal-Rules-NEW

Add rules:

Add another Rule:

Add another Rule:

Add Deny Rule:

Lower down the Deny rule to the end in this section:
